Xinje XC2 Series - 5-3-3．The Input Wiring Of HSC

5 input specifications and wiring methods
5-3-3．The Input Wiring Of HSC
For the input wiring of pulse, it differs according to PLC’s model and counter’s model. Below,
we show several typical wiring method (take XC3-48 PLC as the example):
Increment Mode 1
Pulse+Direction
Mode
2
AB Phase Mode 3
