Xinje XC2 Series User Manual

Appendix 1 special soft device list
FD8075 Y01 corresponds with I** 1 Initial value are all decimal
FD8076 Y02 corresponds with I** 2
…… ……
FD8137 Y77 corresponds with I** 63
4、 I property
ID function Initial value Description
FD8138 X00 property all be 0 0: positive logic;
others: negative logic
FD8139 X01 property
FD8140 X02 property
…… ……
FD8201 X77 property
5、 power-off retentive area of soft components
ID Function Initial Value
FD8202 Start tag of D power off retentive area 4000
FD8203 Start tag of M power off retentive area 3000
FD8204 Start tag of T power off retentive area 640
FD8205 Start tag of C power off retentive area 320
FD8206 Start tag of S power off retentive area 512
FD8207
Start tag of ED power off retentive area 0
FD8209 Pulse director and pulse delay time setting 50ms
6、 Communication
ID Function Initial Description
FD8210
Communicate Mode
(station number)
1
255 (FF) is free mode，
1~254 is modbus station number
FD8211 Communicate format 8710
Baud rate, Data bit, stop bit,
parity
FD8212
Judgment time of ASC
timeout
3
Unit ms, if set to be 0, it means no
timeout waiting
FD8213
Judgment time of reply
timeout
300
Unit ms, if set to be 0, it means no
timeout waiting
FD8214 Start ASC 0 High 8 bits invalid
FD8215 End ASC 0 High 8 bits invalid
COM1
FD8216 Free format setting 0
8/16 bits buffer;
With/without start bit，
With/without stop bit
FD8220
Communicate Mode
(station number)
8710
255 (FF) is free mode，
1~254 is modbus station number
COM2
FD8221 Communicate format 3
Baud rate, Data bit, stop bit,
parity
