Xinje XC2 Series User Manual

Appendix 1 special soft device list
FD8222
Judgment time of ASC
timeout
300
Unit ms, if set to be 0, it means no
timeout waiting
FD8223
Judgment time of reply
timeout
0
Unit ms, if set to be 0, it means no
timeout waiting
FD8224 Start ASC 0 High 8 bits invalid
FD8225 End ASC 0 High 8 bits invalid
FD8226 Free format setting 8710
8/16 bits buffer;
With/without start bit，
With/without stop bit
FD8230
Communicate Mode
(station number)
8710
255 (FF) is free mode，
1~254 is modbus station number
FD8231 Communicate format 3
Baud rate, Data bit, stop bit,
parity
FD8232
Judgment time of ASC
timeout
300
Unit ms, if set to be 0, it means no
timeout waiting
FD8233
Judgment time of reply
timeout
0
Unit ms, if set to be 0, it means no
timeout waiting
FD8234 Start ASC 0 High 8 bits invalid
FD8235 End ASC 0 High 8 bits invalid
COM3
FD8236 Free format setting 8710
8/16 bits buffer;
With/without start bit，
With/without stop bit
7、 Subsection Power-off Retentive Zone of Timer T
Nr. Function
Initial
Value
FD8323 Set the retentive zone’s start tag of 100ms non-accumulation timer
FD8324 Set the retentive zone’s start tag of 100ms accumulation timer
FD8325 Set the retentive zone’s start tag of 10ms non-accumulation timer
FD8326 Set the retentive zone’s start tag of 10ms accumulation timer
FD8327 Set the retentive zone’s start tag of 1ms non-accumulation timer
FD8328 Set the retentive zone’s start tag of 1ms accumulation timer
FD8329 Set the retentive zone’s start tag of 1ms precise timer
8、 Subsection power-off retentive zone of counter C
Nr. Function Initial Value
FD8330 Set the retentive zone’s start tag of 16 bits positive counter
FD8331 Set the retentive zone’s start tag of 32 bits positive/negative counter
FD8332 Set the retentive zone’s start tag of single-phase HSC
FD8333 Set the retentive zone’s start tag of dual-phase HSC
FD8334 Set the retentive zone’s start tag of AB-phase HSC
