Xinje XC2 Series User Manual

8 expansion devices
Items Analogue Input (AD)
Temp. input（PT）
Analogue output (DA)
Current
0～
20mA
4～
20mA
Analogue Input
Voltage
0～5V
0～10V
PT100 -
Temperature Range - -100~350℃ -
Max input range DC0～40mA - -
Current
0～10V
0～5V
Analogue output
range
- -
Voltage
0～20mA
4～20mA
Digital input range - - 10 bits binary (0~1023)
Digital Output range 16 bits binary (0~65535) -1000~3500 -
Distinguish Ratio 1/16383(16Bit) 0.01℃ 1/1023(10Bit)
PID Output value 0~K4095 -
Integral precision 0.8% ±0.01℃ 0.8%
Convert speed 20ms/CH 3ms/CH
Power supply DC24V±10%，100mA
Specification 2
●
2CH 16bits analogue input、2CH PT100 temperature input and 2CH 10bits analogue output
●
2CH input/output is current, voltage selectable (current: 0~20mA、4~20mA; voltage: 0~5V、
0~10V), select via XCPPro;
●
2CH A/D and 2CH PT input has PID auto tune function;
●
Adopt DC-DC power supply isolation design, enhance the anti-interfere ability;
●
The display precision is 0.01℃
●
Set each channel’s PID value separately, equipped separate register space;
●
Support real time PID auto tune function; enable the device to PID auto tune under every
status (cold status, heating status, transition status etc), get the best PID values;
●
Realize data exchange with FROM and TO instructions, enhance the flexibility, reduce the
data exchange quantity, expand the data memory space;
