XP3 PLC/HMI Hardware Manual Page 11 of 42 LMAN007_R2V2
In the following, we describe some keys and their functions
Keys Functions
Create a new project
Open a saved project
Save the editing project
Cut the text in the display area
Copy the text in the display area
Paste the text in the display area
Create a new screen, it’s function is the same with [New]
Show the current screen’s attribution content
Copy a screen to another screen
Delete the current screen
Enter alarm list information, every piece of alarm information
corresponds with a middle relay
Assign the system’s initial screen. When the model is
working, press this key to return directly to the initial screen.
Generally the screen is the main menu screen to the screen,
which used mostly; Set the system’s password; Set the
alternate control register’s ID.
Set whole bureau function keys
Via computer’s RS232 port, download the edited project to
XP330 model.
2-3 Add and delete PLC types
