Xray T4 2018 User Manual

22
ACTIVE TOE-IN
901304
SB M3x4
303123-K
SHIM 3x6x2
303129
SHIM 3x6x1
903306
SFH M3x6
ROLL-CENTER
ALU SHIM 3x6x2mm
ALU SHIM 3x6x2mm
5mm THREAD
10mm THREAD
TIGHTEN GENTLY
REAR TRANSMISSION
FRONT TRANSMISSION
L=R
L=R
L=R
ALTERNATIVE
ACTIVE REAR SUSPENSION™
STEP 2
2x
2x
ARS LINKAGE
INITIAL SETTING
INITIAL SETTING
L=R
L=R
ALWAYS USE ONLY THIS POSITION
IMPORTANT
55.5mm
57mm
INITIAL SETTING
1:1
23mm
2x
5. FRONT & REAR TRANSMISSION
COMPOSITE SHIM 3x6x1mm
Do not use for basic set-up
COMPOSITE SHIM 3x6x1mm
Do not use for basic set-up
The angle of the ARS linkage – which is made by adding/
removing shims on the steering block and ARS post mount –
changes the toe-in characteristics of the rear tires under rolling
effect; when the car is pressed the toe-in can either increase
or decrease.
Check the toe-in change on your set-up system when the car
is in neutral position and when is pressed down. For more
information see the HUDY Set-up Book.
5mm THREAD
6mm THREAD
4L
4R
57mm
L=R
REAR LEFT = REAR RIGHT
2x
2x
#307222 TITANIUM FRONT ARM PIVOT PIN (2)
