31
ANTI-ROLL BARS
VIDEO TECH TIP
▶
901304
SB M3x4
901302
SB M3x2.5
4x
5. FRONT & REAR SUSPENSION
17mm
4x
2.0 mm
Install the pivot balls with Professional
Multi Tool (HUDY #183011).
If both sides still do not
move at the same time,
adjust the length of the
bar holders.
When the bars are set, verify that both
sides move at the same time. If they
do, the bars are set up correctly. If not,
make sure that both downstops are the
same and that the bar wire is flat.
Set the bar into the center, remove the play in the bushings, and
tighten the set-screws fully.
CENTER
DETAIL
REAR TRANSMISSION
REAR TRANSMISSION
2x
3x4mm
3x4mm
3x2.5mm
3x2.5mm
SOFTER rear anti-roll bar:
Generates more side traction. Mainly
recommended for low-grip asphalt tracks.
STIFFER rear anti-roll bar:
Helps the car stay flatter and reduces
traction rolling on high-grip surfaces.
4mm Thread
