32
ANTI-ROLL BARS
VIDEO TECH TIP
▶
901304
SB M3x4
901302
SB M3x2.5
5. FRONT & REAR SUSPENSION
FRONT ANTI-ROLL BAR
FRONT ANTI-ROLL BAR
3x4mm
3x4mm
3x2.5mm
3x2.5mm
When the bars are set, verify that
both sides move at the same time.
If they do, the bars are set up
correctly. If not, make sure that
both downstops are the same and
that the bar wire is flat.
If both sides still do not
move at the same time,
adjust the length of the
bar holders.
CENTER
DETAIL
Set the bar into the center, remove the play in the
bushings, and tighten the set-screws fully.
2x
SOFTER front anti-roll bar:
Allows the front to roll more which gives more front grip and improves on-power steering.
STIFFER front anti-roll bar:
Makes the car initially more responsive, and helps the car stay flatter on fast direction changes.
Reduces steering from mid-corner to corner exit. Mainly recommended for high-grip carpet.
