46
BODY UPSTOPS
VIDEO TECH TIP
7. FINAL ASSEMBLY
BODY STOP SYSTEM
The X4 features an adjustable front body upstop system incorporated into the new upper arm to prevent the body shell
from bottoming out and hitting the ground during cornering. When the system is set correctly, it allows the body to be run
lower without dragging on the ground to improve aerodynamic efficiency.
BODY STOP ALTERNATIVE
with screw and ball joint
(#901308 SB M3x8mm / #303457 Ball Joint)
BODY STOP ALTERNATIVE
with screw
(#902316 SH M3x16mm)
(NOT INCLUDED)
(NOT INCLUDED)

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Xray X4 and is the answer not in the manual?

Xray X4 Specifications

General IconGeneral
Scale1/10
Power SourceElectric
Drivetrain4WD
Motor TypeBrushless
Drive Type4WD
Battery TypeLiPo
Battery Voltage7.4V
Radio System2.4GHz
Tire TypeRubber (Not Included)
Body MaterialPolycarbonate
