45
TRACK WIDTH
(OFFSET)
DOWNSTOP & RIDE
HEIGHT
CHASSIS TWEAK
VIDEO TECH TIP
▶
960240
N M4
7. FINAL ASSEMBLY
#309862
XRAY STAINLESS STEEL WEIGHT FOR NARROW
BATTERY PACK 35g
#326181
STAINLESS STEEL BATTERY WEIGHT 35g
#293083
HUDY PURE TUNGSTEN WEIGHT 15g
#293085
HUDY PURE TUNGSTEN WEIGHT THIN ROUND
WITH M3 - 10g
#293082
HUDY PURE TUNGSTEN WEIGHT 10g
#293081
HUDY PURE TUNGSTEN WEIGHT 5g
Make sure the wheel nuts are very tight, so
the wheels do not loosen during operation.
ALU REAR WING SHIM
#353561 SILVER OPTION
#293561 SILVER OPTION
#293561-O ORANGE OPTION
OFFSET ALU WHEEL SHIMS
#305380 0.75mm OPTION
#305382 0.5mm OPTION
#305381 1.0mm OPTION

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Xray X4 and is the answer not in the manual?

Xray X4 Specifications

General IconGeneral
Scale1/10
Power SourceElectric
Drivetrain4WD
Motor TypeBrushless
Drive Type4WD
Battery TypeLiPo
Battery Voltage7.4V
Radio System2.4GHz
Tire TypeRubber (Not Included)
Body MaterialPolycarbonate
