Xray XB808 User Manual

13
DOWNSTOP
WHEELBASE
ANTI-ROLL BAR
REAR SUSPENSION
901312
SB M3x12
901303
SB M3x3
902318
SH M3x18
903308
SFH M3x8
901305
SB M3x5
901408
SB M4x8
960040
N M4
➊
➋
➌
➍
3x5
3x8
L=R
4mm
DOWNSTOP SETTING
L=R
Loosen the 3x5 setscrew if the anti-
roll bar does not turn freely
4x8
Downstop screw
2mm
2mm
Do not overtighten the self-locking
nut. Overtightening may result in
suspension binding.
L=R
2x
3x12
1.5mm
6mm
Follow the TECH TIP on page
5 to install the pivot balls
3x3
L=R
Step check for free movement
➊
0mm
STEP DETAIL
➍
3x18
Step
➊
(HUDY #107634)
ARM REAMER
If the suspension arm does not
move freely use a HUDY Arm
Reamer to size the holes of the arms
Check for free
movement
REAR ARM
L=R
Ensure there is a little play
Ensure there is a little play
DETAIL
DETAIL
INITIAL POSITION
INITIAL POSITION
1
1
2
2
CORRECT
After tightening the
suspension pins the
suspension holders
will slightly bend
which is correct and
will not have any negative effect. However it is very
important to ensure that the suspension arm moves
freely with no binding. When tightening the self-
locking nut, ensure that the thread on the pin goes
into the nylon insert inside the end of the nut.
