Xray XB808 User Manual

15
REAR SUSPENSION
CAMBER
ROLL CENTER
WING ANGLE
902322
SH M3x22
902316
SH M3x16
960030
N M3
905314
SP 3x14
960030
N M3
902318
SH M3x18
902320
SH M3x20
902310
SH M3x20
Follow the TECH TIP on page 5
to install the pivot balls
DETAIL
Use tools to tighten as shown
INITIAL POSITIONS
INITIAL POSITIONS
Right thread Left thread Right threadLeft thread
37.5 mm
INITIAL POSITIONS
RIGHT
THREAD
LEFT
THREAD
3x16
3x22
3x18
3x10
3x20
NOTE ORIENTATION
Adjustment block towards outside
3x14
3x14
37.5 mm
NOTE ORIENTATION
Adjustment block towards outside
1
1
2
2
3
3
RIGHT
THREAD
LEFT
THREAD
1
1
2
2
3
3
4
4
F1
F1
F3
F3
F2
F2
F4
F4
R1
R1
R3
R3
R2
R2
R4
R4
Follow the TECH TIP on page 5
to install the pivot balls
1
1
2
2
3
3
4
4
For stiffer wing mounting use optional
alu wing mount brace #353550.
