Xray XB808 User Manual

34
REAR SHOCK
960030
N M3
901303
SB M3x3
902310
SH M3x10
903314
SFH M3x14
961022
S 2.2
902319
SH M3x18
LEFT thread
902325
SH M3x25
902318
M3x18
FINAL ASSEMBLY
3x18
REAR SHOCKS (LONG)
3x10
Brake rod
Throttle rod
Thread brake rods into plastic
pivots until flush with outer end
3x14
SILICONE
TUBING
10mm
Brake rod
Tighten screw until snug.
Pivots should move freely.
CUTAWAY VIEW
Use servo horn to match your servo
K - KO Propo F - Futaba H - Hitec
Servo screw
(not included)
3x25
L=R
INITIAL POSITIONS
INITIAL POSITIONS
On the rear left arm use the SILVER M3x18
screw - this screw has LEFT THREAD
Use STANDARD
M3x18 screw
SHORT
1
1
2
2
Ensure that the servo is in neutral position
before attaching the servo horn.
OUTER
OUTER
INNER
INNER
LOWER
LOWER
UPPER
UPPER
Always use UPPER shock position on front
shocktower in combination with INNER hole
on suspension arm.
Always use LOWER shock position on front
shocktower in combination with OUTER hole
on suspension arm.
Always use LOWER shock position on rear
shocktower in combination with OUTER hole
on suspension arm.
Always use UPPER shock position on rear
shocktower in combination with INNER
hole on suspension arm.
LOWER
LOWER
UPPER
UPPER
FRONT SHOCK
POSITIONS
REAR SHOCK
POSITIONS
UPPER
UPPER
LOWER
LOWER
3
3
2
2
1
1
1
1
2
2
3
3
1
1
2
2
3
3
1
1
2
2
3
3
UPPER
UPPER
LOWER
LOWER
OUTER
OUTER
INNER
INNER
Clearance
Clearance
