Xray XB9 User Manual

25



903314
SFH M3x14
903410
SFH M4x10
903310
SFH M3x10
903312
SFH M3x12
960030
N M3
902308
SH M3x8
902310
SH M3x10
960030
N M3
903320
SFH M3x20
303122
SHIM 3x6x1
303123
SHIM 3x6x2
961032
S 3.2
step
step
STEERING
INITIAL POSITION
Follow the TECH TIP on page 5
to install the pivot balls
RIGHT
THREAD
LEFT
THREAD
32.8 mm
32.8 mm
4x10
SFH 3x12
SFH
3x10
SFH
3x14
SH
3x10
SH
3x10
SH 3x8
SH 3x8
2mm
alu shim
1mm
alu shim
3x20
3x20
NOTE ORIENTATION
Adjustment block towards outside
Left threadRight thread Left thread Right thread
NOTE ORIENTATION
Adjustment block towards outside






Check for free
movement
Follow the TECH TIP on page 5
to install the pivot balls
RIGHT
THREAD
LEFT
THREAD
Check for free
movement
OPTIONAL
XB9 GRAPHITE UPPER PLATE WITH
ALU REINFORCEMENT STAND
#351343
