OWNER’S INSTALLATION LOG
Upon installation of your mobile audio sound system, your
Authorized Xtant Select Dealer will complete this log. Keep this
owner’s manual with your vehicle as a reference for all amplifier set-
tings.
owner’s name:
Vehicle: year:
xtant amplifier serial no.
input sensitivity
(CIRCLE SETTING)
Front Inputs Rear Inputs
–20 dB –10 dB 0 dB +10 dB +20 dB –20 dB –10 dB 0 dB +10 dB +20 dB
Front Crossover Rear crossover
CIRCLE JUMPER SETTING
: CIRCLE JUMPER SETTING:
Amplifier: byp high low BND Amplifier: byp high low BND
rca outputs: byp high low BND rca outputs: byp high low BND
frequency value frequency value
SIP High Pass FQ SIP High Pass FQ
sip low pass FQ sip low pass FQ
output gain adjustment noise gate adjustment
switch: on off
threshold position
(DRAW ARROW POSITION)(DRAW ARROW POSITION)
Accessory modules (CIRCLE SETTING)
LFQ45 front rear pqm-1 (FRONT) yes no
yes no yes no
pqm-1 chip frequency
RGM 1
front rear pqm-1 (REAR) yes no
yes no yes no
pqm-1 chip frequency
Balanced Line Input Passive Outputs
front rear RM4 RM8 RM12 RM16
yes no yes no yes no yes no yes no yes no
Xtant Select Dealer
phone: date installed:
installation specialist:
