Xtant 604X SPECIFICATIONS
Frequency Response: 5 Hz to 50 kHz +/– 1 dB
Number of Channels: 4
Watts per Channel @ 4Ω: 4 x 75
Watts per Channel @ 2Ω: 4 x 150
Bridged Mono @ 4Ω: 2 x 300
Recommended Load: >2Ω Stereo / >4Ω Bridged
Distortion (THD): < .04%
Measured: 20 Hz to 20 kHz at rated power, all channels driven 4Ω
Signal to Noise Ratio: > 100 dB
Measured: A-weighted in 20 kHz noise bandwidth @ 1 volt sensitivity
Damping Factor: > 200 @ 100 Hz with 4Ω load
Input Sensitivity: 100 mV to 8.5 V RMS Unbalanced Source
100 mV to 17 V RMS Balanced Source
Input to Line Output Gain: 0 dB +/– 20 dB,
Selectable in 10 dB steps
On-Board Crossover: 12/24 dB/Octave Butterworth
Module Port(s): 4 – Accessory
Balanced Line: 2 – On Board
Passive Outputs: 2 Channels; RM8 provided
Power Supply: Fully Regulated, PWM
Operational Voltage: 11 to 15 Volts
Fusing Requirement: 120 Amp
Size (L xW x H): 23.63 x 8.875 x 2.145”
Warranty: Limited 4 Year Parts and Labor
SEE PAGE ELEVEN OF THIS MANUAL FOR COMPLETE DETAILS
