ON-BOARD ELECTRONIC CROSSOVER
All Xtant “X” series amplifiers have on-board, two-way elec-
tronic crossovers. Xtant 3 and 4 channel models feature two inde-
pendent two-way crossovers. Each crossover is tied to a set of inputs and con-
trols the frequency range of the associated amplifier. Independent frequency
selection is provided for both the High and Low Pass sections. A set of selec-
table RCA line outputs (to feed additional components) are included with
each crossover. In addition, each crossover features four on-board header
jumpers (two for the amplifier and two for the RCA line outputs) which
allow you to select Bypass (Full Range), High Pass, and/or Low Pass modes.
The “X” Series models offer an additional Band Pass selection. When chosen,
the Band Pass selection is
available via the Low Pass jumper position for the
RCA line outputs.
The following Frequency Modules (SIPs)* are available from your Xtant
Dealer: 50 Hz, 70 Hz, 80 Hz, 90 Hz, 120 Hz, 150 Hz, 300 Hz, 500 Hz, 700 Hz,
1 kHz, 3 kHz, 4 kHz, and 5 kHz.
Please refer to the Installer’s Reference (insert) for the Frequency Module recep-
tacle location and chart of frequency/SIP value code numbers
* SIP: an acronym referring to multiple resistors in a Single In-Line Package
7
