Xterra FS4.0e - Page 6

4
FS4.0e Elliptical
FS4.0e Assembly Pack Checklist
Hardware Step 1
#97. 5/16” x 23 x 1.5T
Flat Washer
(4 pcs)
#70. 5/16” x 15mm
Hex Head Bolt
(6 pcs)
#102. 5/16” x 23 x 2T
Curved Washer
(2 pcs)
#70. 5/16” x 15mm
Hex Head Bolt
(2 pcs)
Hardware Step 2
#97. 5/16” x 23 x 1.5T
Flat Washer
(2 pcs)
#75. 5/16” x 15mm
Button Head Socket
Bolt (6 pcs)
#101. 17mm
Wave Washer
(2 pcs)
#78. M5 x 10mm
Phillips Head Screw
(4 pcs)
