Xterra FS4.0e - Assembly Tools

FS4.0e Elliptical
5
Assembly Tools
#76. 5/16” x 3/4”
Button Head Socket
Bolt (2 pcs)
#71. 5/16” x 32mm
Hex Head Bolt
(2 pcs)
Hardware Step 3
#84. 3.5 x 12mm
Sheet Metal Screw
(8 pcs)
#79. M5 x 15mm
Phillips Head Screw
(8 pcs)
Hardware Step 4
#108. M5 Allen Wrench /
Phillips Head Screw Driver
#111. 13/14mm Wrench
(2 pcs)
#110. 12mm Wrench
#77. 3/8” x 2-1/4”
Button Head Socket
Bolt (2 pcs)
#94. 3/8” x 19 x 1.5T
Flat Washer
(2 pcs)
#89. 3/8” x 7T
Nyloc Nut
(2 pcs)
#98. 5/16” x 20 x 1.5T
Flat Washer
(4 pcs)
#105. 5/16” x 7T
Nyloc Nut
(2 pcs)
