Xtralis XAS-2-USProduct Guide Xtralis Pty Ltd
24V+
24V-
Loop OUT +
Loop OUT -
Loop IN +
Loop IN -
NO
COM
NC
FAULT 2
I/O
Module
Loop +
Loop -
Loop +
Loop -
24VDC
+-
-+
-+
NO
COM
NC
FAULT 1
To previous device
or control panel terminals
To next device
(if applicable)
Figure2-7: Wiring diagram for an XAS-2-US system with analogue point detectors and one I/OModule
24V+
24V-
Loop OUT +
Loop OUT -
Loop IN +
Loop IN -
NO
COM
NC
FAULT 2
I/O
Module
Loop +
Loop -
Loop +
Loop -
24VDC
+-
-+
-+
I/O
Module
+- -+
NO
COM
NC
FAULT 1
To previous device
or control panel terminals
To next device
(if applicable)
Figure2-8: Wiring diagram for an XAS-2-US system with analog point detectors two I/OModules
10 www.xtralis.com
