8 Specifications
Number of Detectors
(not supplied)
2 Analog Addressable or Conventional
Dimensions (L x W x H) 10.2 in x 6.52 in x 12.6 in (258.6 mm x 165.7 mm x 320.6 mm)
Weight 7.5 lbs (3.4 kg)
Filtration Single stage dust particle filter.
Optional external filter.
Flow Monitoring l Thermal device, high and low thresholds.
l 10 element bar graph indication.
l Relay fault reporting.
Supply Voltage 18 - 30 VDC (24 VDC Nominal)
Relays l Fault 1: 1 A @ 30 VDC
l Fault 2: 1 A @ 30 VDC
Maximum Supply Current 350 mA @ 24 VDC with no aspirating pipe. See table below for typical
Currents/Fan Speeds
In-Rush Current 680 mA for 30 milliseconds
Maximum Pipe Length Up to 50 m per pipe dependant on detector type & application
Air Inlet Pipe Accepts both metric and American standard pipe sizes.
l Metric: 25mm (1.05 in.)
l American Pipe: ¾ in. I.D (21mm)
l Flexible tubing: ¾ in.O.D (19mm)
Aspirator l Control: 10 programmable speeds
l Pressure: 250 Pa
Environmental Protection l Wiring enclosure:IP30
l Detector enclosure: IP65
Operating Conditions l Tested to: 14 to 131 °F (-10 to 55 °C)
l Recommended Detector Ambient: 32 to 100 °F (0 to 38 °C)
l Sampled Air: 4 to 140 °F (-20 to 60 °C)
l Humidity:10 to 95% RH (non-condensing)
Certification UL-268
UL-268A
ULC-529
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including
interference that may cause undesired operation
Xtralis Pty Ltd Xtralis XAS-2-USProduct Guide
www.xtralis.com 45
