Threaded 90 Elbow Reducer Adaptor for exhaust port LF42206 1
Duct Mount Plate Assembly LF42207 3
Smoke Test Port Pipe 8" (280 mm) LF42212 1
Smoke Test Port Pipe 7 7/8" (200 mm) LF42213 1
Smoke Test Port Rubber Plug LF42214 2
Exhaust Port Pipe LF42276 1
Table3-6: Water Trap Kit Parts List (LF42283)
Name Part Number Quantity
90 Degree Bend (Box of 20) VP-ELB-90 6
Transparent Pipe (imperial for US) LF42210 2
Ball Valve LF42211 2
Tee Pipe (Box of 15) VP-TEE 2
Horizontal Inlet Pipe (160 mm) LF42277 2
Vertical Water Trap Pipe 7 7/8" (200 mm) LF42278 4
Horizontal Water Trap Pipe (100 mm) LF42279 1
Couplings (Box of 15) VP-COUP 1
