Xtreme XR1255 User Manual

Page 20 Xtreme Manufacturing, LLC
Labels XR1255
Table 1. Labels
Item Qty. Part No. Description
1 1 18008-000 Data Plate
2 1 18001-002 Dash Overlay
3 1 18010-001 Caution, Slip/Trip Hazard
4 1 18011-001 Caution, Engine Damage
Hazard
5 1 18013-001 Diesel Only
6 1 18014-001 Check Engine Oil
7 1 18015-001 Check / Fill Coolant
8 1 18016-001 Caution, Burn Hazard
9 2 18017-001 Danger, Crushing Hazard
10 8 18018-001 Danger, Electrocution Hazard
11 1 18018-002 Danger, Electrocution Hazard
12 3 18019-001 Danger, Crushing Hazard
13 1 18020-001 Warning, Tip Over Hazard
14 1 18021-001 Danger, Crushing Hazard
15 1 18022-001 Warning, Tip Over Hazard
16 1 18023-001 Warning, Welding Modication
Hazard
17 1 18025-001 Warning, Falling Hazard
18 1 18026-001 Warning, Unrestrained
Operator Hazard
19 1 18027-001 Danger, Rotating Equipment
Hazard
20 1 18031-001 Warning, Safe Operation
Checklist
21 1 18032-001 Warning, Improper Use Hazard
22 1 18033-100 Auxiliary Handle Control
23 1 18347-000 Boom Handle Control
24 1 18039-000 Angle Indicator
25 6 18041-001 Warning, Pinch Point Hazard
26 3 18042-000 Xtreme Logo
27 2 18066-001 Caution, Crushing Hazard
28 1 18067-100 Frame Sway Handle
29 1 18334-001 Handle Auxiliary Controls
30 1 18069-000 Hydraulic Tank Fluid Level
31 1 18082-001 Warning, Injection Hazard
32 2 18083-001 Warning, Explosion Hazard
33 1 18086-001 Hydraulic Fluid, Use Dexron III
34 4 18090-001 Warning, Tip Over Hazard
35 2 18300-001 Warning, Falling Hazard
36 2 18312-000 Warning, Falling Hazard
37 4 18315-000 Tie Down Point
38 2 18043-000 Xtreme Logo
39 3 18044-000 Xtreme X
40 1 18046-000 Boom Swoosh Left Front
41 1 18047-000 Boom Swoosh Left Rear
Item Qty. Part No. Description
42 1 18048-000 Boom Swoosh Right Front
43 1 18049-000 Boom Swoosh Right Rear
44 2 18372-000 XR1255
45 1 18056-000 Boom Lettering, A-B-C-D
46 1 18057-000 Boom Lettering, E-F
47 1 18058-000 Boom Lettering, G-H
48 1 18311-002 Boom Hook, 12K
49 1 18331-000 Caution, Adjustable Carriage
50 1 18332-000 Warning, Tow Capacity
51 1 18307-001 Warning, Falling Hazard
52 1 18306-001 Danger, Crushing Hazard
53 1 18306-000 Danger, Crushing Hazard
54 1 17250-000 Load Chart, Standard Carriage OR Up
55 1 17251-000 Load Chart, Standard Carriage OR Down
