For information call (800) 497-1704 Page 37
XR1255 Operator Cab
Warning
DO NOT adjust the seat or seat belt while
the forklift is moving. Keep both hands on
the wheel while the forklift is moving to
prevent loss of forklift control which could
result in death or serious injury.
Before starting the engine, adjust the seat for position and
comfort (refer to the Operator Seat section of this manual)
and then adjust the seat belt as follows:
1. Grasp the free end of the seat belt (located on the left
side of the seat) and make sure the belt webbing is
not twisted or entangled in any portion of the seat
assembly.
2. Pull the retractable seat belt across your lap. Position
the seat belt as low on your body as possible.
3. Insert the latch plate into the buckle (on the right side
of the seat) until a “click” is heard.
4. Make sure seat belt retracts snugly across your lap.
Rear View Mirrors
Two (2) adjustable rear view mirrors are provided to aid
the operator’s rear vision. One (1) rear-view mirror is
mounted on the upper left of the operator’s cab.
Figure 6-14. Cab-Mounted Mirror.
One (1) rear-view mirror is mounted on the frame.
Figure 6-15. Frame Mounted Mirror.
