Xylem Sensus Cordonel DN 40 User Manual

Values Unit DN 40 DN 50 DN 65 DN 80 DN 100
Data logger reverse volume Off
Data logger net volume On
Data logger alarm status On
Readout on … day of month Day: 1
Key date value of forward volume Off
Key date value time minimum flow rate Off
Key date value minimum flow rate Off
Key date value time pipe burst Off
Key date value pipe burst Off
Key date value instantaneous flow rate 1 Off
Key date value time peak flow rate 2 Off
Key date value peak flow rate 2 Off
Key date value time maximum flow rate 3 Off
Key date value maximum flow rate 3 Off
Key date value minimum pressure Off
Key date value time minimum pressure Off
Key date value maximum pressure Off
Key date value time maximum pressure Off
Key date value minimum temperature Off
Key date value time maximum temperature Off
Key date value maximum temperature Off
Key date value time maximum temperature Off
Key date value current pressure Off
Key date value current temperature Off
Key date value extended alarms Off
Key date value reverse volume Off
Key date value net volume On
Key date value alarm status On
Wake up interval Sec. 3
UTC time shift Hours 0
Pulse On
Pulse mode A4 balanced pulse
Pulse value Litres 100
Pulse length ms 500
1) The instantaneous flow rate is the mean value of the logger period
2) The peak flow rate is the mean value over 2 seconds
3) For maximum flow rate, see section10
14. Temperature measurement
The Cordonel measures the water temperature. The measurement is performed directly by the ultrasonic signal. The measured temperature is
shown on the display in line 2 and can be transmitted by radio via the SEMI data protocol of SensusRF.
15. Optional pulse output
The Cordonel is equipped with a slot for a pulse adapter.
If the Cordonel is delivered without a pulse module, the slot is fitted with a dummy to protect it against contamination.
The dummy must be removed before installing the pulse module. When doing so, make sure dirt does not enter the slot. If the slot is dirty, it must
be cleaned carefully by rinsing and wiping it with a soft cloth. Avoid scratching the surface.
If the pulse module has been installed, the cable must be routed directly from the Cordonel meter towards the bottom of the meter.
Cordonel
Page 10
