ProTURN SLX 1630 ProtoTRAK SLX CNC Safety, Installation, Maintenance, Service & Parts List Manual
96
1630 Headstock Parts List
Item
Parts No.
Description
Material
Specification
Q’ty
1
21234-004
Center
SK5
MT#4
1
2
50-01120A
Driving Plate - 8”
FC25
D1-6
1
3
50-01119
Cam Lock Stud
SCM415
D1-6
6
4
Socket Head Cap Screw
M6x45L
6
5
24715
Cover - Bearing (Front)
FC20
25-0105
1
6
25-0101
Headstock Casting
FC25
1
7
50-01113
Positioning Pin
S45C
1
8
21234-003
Center Sleeve
SK5
MT#6xMT#4
1
9
24728
Detent Screw
SS41
50-01112
6
10
24729
Detent Spring
SWP
50-01111
6
11
24730
Cam
SCM415
50-01110
6
12
24727
Gasket
25-0106
1
13
21234-015
Bearing - Taper Roller - front
#32016XJ
1
14
24718
Key – spindle encoder gear
6x6x20L
1
15
24705
Spindle
SCM440
25-0102
1
16
24717
Snap Ring
S-78
2
17
24706
Gear – Main Spindle
S45C
77USA-0146
1
18
24732
Key
6x6x20L
1
19
24733
Snap Ring
S-17
1
20
24707
Gear – Spindle Encoder
S45C
77USA-0145
1
21
6003-2RS
Deep Groove Ball Bearing
6003
2
22
Socket Head Cap Screw
M12x1.75X55L
1
23
50-01114
Adjusting Block
SS41
1
24
24724
Spacer
SS41
24-0127
1
25
24722
Ring – Mounting, spin enc
FC20
25-0142
1
26
24721
Shaft – spindle encoder
S45C
25-0143
1
27
Socket Head Cap Screw
M6xP1.0x16L
3
28
24719
Spacer - spindle
S45C
25-0109
1
29
24708
Pulley - Spindle
FC30
25-0110
1
30
24709
Lock Nut – Spindle Pulley
SS41
SK70
60-0163
1
31
24726
Gasket
25-0108
1
32
24710
Bearing - Taper Roller - rear
#32015XJ
1
33
Socket Head Cap Screw
M6x20L
6
34
24716
Cover - Rear
FC20
25-0107
1
35
24720
Key – spindle pulley
8x7x45L
2
36
24711
Pump – Oil - Manual
AM2A
1
37
Hexagon Head Screw
M6x45L
3
38
Washer - Spring
M6
3
39
24723
Bracket – oil pump
SS41
25-0112
1
40
Socket Head Set Screw
M5x16L
2
