XYZ Machine Tools
ProTURN SLX 1630 ProtoTRAK SLX CNC Safety, Installation, Service & Parts List Manual
2.5 Machine Specifications
Capacity
SLX 1630
Height of Centers
203.2 mm
Distance Between Centers
762 mm
Swing Over Bed
406.4 mm
Swing Over Saddle Wings
406.4 mm
Swing Over Cross Slide
218.4 mm
Cross Slide Travel
215.9 mm
Tool Section Max.
19 mm
Coolant
41.6 liter
Oil Pump – Way Lubrication
2 liter
Oil Reservoir – Headstock
13.3 liter
Bed
Width
320 mm
Height
320 mm
Headstock
Spindle Nose
D1-6
Spindle Through Hole
53.9 mm
Spindle Taper
MT#6
Taper in Reduction Sleeve
n/a
Spindle Diameter Front Bearing
80 mm
Number of Bearings
2
Bearing Class (Radial Runout)
P5
Number of Spindle Speed Ranges
1
Spindle Speed Range (RPM)
150-2500
Tailstock
Quill Travel
127 mm
Quill Diameter
59.9 mm
Quill Taper Hole
MT#4
Spindle Motor
H.P.
7.5
Voltage
415
Amps, Full Load
13
Phase, Hz
3/50
Dimensions
Net meters L x W x H kg.
2.08 x 1.02 x 1.80m, 998
Ship meters L x W x H kg.
2.21 x 1.14 x 1.70m, 1247
Other
Coolant Pump Motor, H.P.
1/8
Spindle Motor Brake
Dynamic Braking
Way Surface Hardness
400-450 HB
Headstock Lubrication
Oil Bath
Options
Steady Rest (Type, Diameter)
Roller 12.7 – 139.7 mm
Tooling Kit
20 mm
Chuck
203 mm, D1-6
Indexer Option – 8 tool
20 mm
Indexer Option – 4 tool
20 mm
Gang Tooling
n/a
Noise Emissions (workstation) max RPM running
with no material
69dB (A)
