ProTURN SLX 1630 ProtoTRAK SLX CNC Safety, Installation, Service & Parts List Manual
3.5.5.2 Leaking Oil From Front of Gearbox
Possible Cause
Check This
Oil leaking between cover and gearbox
Remove gearbox cover. Thoroughly clean cover & top
of gearbox. Replace gasket and reassemble.
3.5.6 Tailstock Barrel is Stiff
The tailstock barrel is stiff or not smooth moving through its travel. The tailstock
barrel subassembly jams inside the tailstock.
Possible Cause
Check This
Misalignment of tailstock housing
Realign bearing housing and tailstock screw. Loosen
screw support and realign.
Too much grease.
Disassemble and remove excess grease.
Vernier Dial is binding or rubbing on
screw support.
Remove dial and machine off a couple of thousandths
or shim.
