ProTURN SLX 1630 ProtoTRAK SLX CNC Safety, Installation, Service & Parts List Manual
49
23337-73
Wiper - Bedway (Left, Rear)
Rubber
24-0336
1
50
Hexagon Socket Screw
M5x6L
8
57
22446
Bearing - self aligning
2204E-2RS1TN9
1
58
N04
Lock Nut
S45C
N04(20x16UNF)
1
59
W04
Lock Washer
W04
1
60
16295-1
Bearing Housing
FC20
1
61
Socket Head Cap Screw
M12x50L
4
62
Washer - Spring
M12
4
63
Socket Head Cap Screw
M6x20L
2
64
25-0321
Bumper
Rubber
2
65
25-0320
Cam
SS41
1
66
Socket Head Cap Screw
M8x70L
2
67
23337-82
Wiper - Bedway (Right, Front)
Rubber
25-0335
1
68
24714
Gib - X Axis
FC30
25-0217
1
69
17-0321-00
Screw - Adjusting
S30C
2
70
Socket Head Cap Screw
M8x25L
4
71
25-0201
Saddle
FC25
1
72
Socket Head Cap Screw
M12x65L
4
73
23337-81
Wiper - Bedway (Left, Front)
Rubber
25-0334
1
74
24704
Ballscrew - Z Axis
SCM415
25-0310
1
75
Cover - Bearing
AVH7205
1
76
23940
Bearing Set - Angular Contact Ball
7205 BECBP
2
77
SLX 16302
Spacer
S45C
1
78
24A-0308
Seat - Bearing
S45C
1
79
Socket Head Cap Screw
M8x25L
4
80
16452
Nut - Clamp
S45C
19x16UNF
1
81
24A-0216
Cone Clamping Element
Brass
1
82
16983-1
Pulley-ballscrew
Aluminum
1
83
98481A090
Woodruff Key
#3 (1/8"x1/2")
1
84
W01
Lock Washer
W01 (12)
1
85
N01
Lock Nut
N01 (12x32UNF)
1
86
Set Screw
M5x10L
3
87
Socket Head Cap Screw
10-32x3/4"
1
88
Socket Head Cap Screw
M12x35L
4
89
400-5M-15
Belt - Z Axis
400-5M-15
1
90
Pulley
Aluminum
5M-30T
1
91
Socket Head Cap Screw
1/4-20UNCx30L
4
92
Washer - Flat
1/4"
4
93
Washer -Spring
1/4"
4
94
77USDA-0304
Base - Motor - Z Axis
FC30
1
95
24425
Motor - Z Axis Servo
1
96
25-0223
Cover Plate (Front)
SS41
1
I01153.xls
5.1.15 Headstock Taper Adjustment
The headstock may be adjusted to remove turning taper if the taper is caused by a
lack of parallelism of the headstock to the bed ways. Ensure that the level of the bed
is correct prior to any headstock adjustments.
To adjust the headstock alignment, loosen the four socket head cap screws that
attach the headstock housing to the bed. Using the adjusting screw located at the
