2.6 ProtoTRAK SLX Control Hardware
2 -axis CNC, 2-axis DRO
400 MHz PC-based processor
256 MB of RAM
D.C. Servo Motors rated at 280 in-oz continuous torque for X, and 560 in-oz for
the Z-axis.
Precision ground ballscrews in the carriage and cross-slide to ensure smooth
accurate contours without backlash
Feedrate override of programmed feedrate and rapid
Speed override of programmed RPM
Polycarbonate sealed membrane and gasket sealed control enclosure to lock out
contamination
266.7 mm color LCD for clear presentation of prompts, status information and
part graphics
Modular design simplifies service and maximizes uptime
256 MB flash drive
(2) USB Ports
Single floppy disk drive for additional part program storage
2.7 Lifting and/or Moving the Machine
CAUTION!
The 1630 machine weighs approximately 1247 kg when shipped. Proper equipment of sufficient capacity
must be used when lifting and/or moving the machine.
To lift the machine, remove the chip pan. Place the forks of the forklift at least 813
mm apart as shown in the figure 3. Be certain to lift the lathe toward the headstock.
