ProTURN SLX 1630 ProtoTRAK SLX CNC Safety, Installation, Maintenance, Service & Parts List Manual
101
Parts List
Item
P/N
Mfr P/N
Title
UseAs
1
22712-1
24-0501-00
TAILSTOCK BODY
EA
2
M10-1.5X60 25B
SCREW-SHCS-STL-BO
EA
3
M12-1.75X16 25B
SCREW-SHCS-STL-BO
EA
4
M12-1.75X25 25B
SCREW-SHCS-STL-BO
EA
5
22712-5
10X40LG
STRAIGHT PIN
EA
6
M6-1.0X10 40B
SCREW-SOC SET-STL-BO-CUP
EA
7
M8-1.25X10 40B
SCREW-SOC SET-STL-BO-CUP
EA
8
22712-8
TCØ60XØ75X9
OIL SEAL
EA
9
22712-9
Ø1/4
BALL CUP
EA
10
22712-10
23-0112-00
WASHER-Ø10.5X25.4XT2
EA
11
22712-11
24-0502-00
TAILSTOCK BASE
EA
12
22712-12
50-0503-00
SLEEVE-TAILSTOCK BARREL
EA
13
22712-13
50-0505-00
FEED NUT-IMPERIAL
EA
14
22712-14
50-0505-01
SHCS-M6-1.0X12
EA
15
22712-15
24-0507-00
FEED SCREW-IMPERIAL
EA
16
22712-16
6X6X20LG
DOUBLE ROUND HEAD KEY
EA
17
M5-0.8X20 40B
SCREW-SOC SET-STL-BO-CUP
EA
18
22712-18
50-0508-00
BRACKET
EA
19
M6-1.0X30 25B
SCREW-SHCS-STL-BO
EA
21
22712-21
51104
THRUST BEARING
EA
22
22712-22
50-0510-00
DIAL-IMPERIAL
EA
23
22712-23
50-0511-00
HANDWHEEL
EA
24
22712-24
50-03111-00
LOCKSCREW
EA
25
22712-25
50-0513-00
WASHER
EA
26
22712-26
50-0514-00
PIN
EA
27
22712-27
50-0515-00
LOCKING BLOCK
EA
28
22712-28
50-0516-00
CLAMPING BLOCK
EA
29
22712-29
50-0517-00
LOCKING ROD
EA
30
22712-30
50-0518-00
LEVER
EA
31
22712-31
50-0519-00
SHAFT
EA
32
22712-32
50-0520-00
LEVER
EA
33
22712-33
50-0521-00
ECCENTRIC COLLAR
EA
34
22712-34
Ø6X40LG
SPRING PIN
EA
35
22712-35
50-0522-00
ADJUSTING BLOCK
EA
36
22712-36
50-0523-00
FLAT WASHER
EA
37
22712-37
50-0524-00
FLAT WASHER
EA
38
22712-38
50-0525-00
COMPRESSION WASHER
EA
39
22712-39
50-0526-00
FLAT WASHER
EA
40
22712-40
S35C
HEX SCREW
EA
41
22712-41
24-0528-00
CLAMPING BLOCK
EA
42
22712-42
24-0528-00
CLAMPING BLOCK
EA
43
22712-43
24-0530-00
BEDWAY WIPER
EA
44
M6-1.0X16 10B
SCREW-PH-PHIL-STL-BO
EA
45
22712-45
24-0531-00
BEDWAY WIPER PLATE
EA
46
22712-46
24-0532-00
BEDWAY WIPER
EA
47
M6-1.0X15 10B
SCREW-PH-PHIL-STL-BO
EA
48
22712-48
24-0533-00
BEDWAY WIPER PLATE
EA
