ProTURN SLX 1630 ProtoTRAK SLX CNC Safety, Installation, Maintenance, Service & Parts List Manual
93
1630 Overall Machine Parts List
Item
Parts No.
Description
Material
Specification
Q’ty
41
Ring - Retaining
S17
3
42
77A-0614
Shaft
S20C
3
43
FVS65
Bearing - Deep Groove Ball
#6203ZZ
3
44
25-0713
Guide Way - Upper Door
SS41
1
45
77-0627
Spacer
S20C
4
46
77-0628
Spacer
S20C
2
47
77-0626
Roller
S45C
2
48
Socket Head Cap Screw
M6x12L
5
49
25-0725
Guide Way - Lower
S45C
1
50
Domed Cap Screw
M10
2
51
77-0629
Shaft
S45C
2
52
22714-58
Bearing - Deep Groove Ball
#6000ZZ
4
53
25-0709
Front Connection Plate
SS41
1
54
25-0726
Safety Door Touch Block
SS41
1
55
24696
Switch - Door
1
56
25-0714
Cover
SS41
1
57
Oil Sight Glass
1
58
25-0724
Anti-Leaking Pad
Rubber
1
59
25-0718
Carrier - Cable
SS41
1
60
25-0720
Cover
SS41
1
61
25-0719
Plate
SS41
1
62
25-0735
Bracket
SS41
1
63
25-0708
Bottom Plate
SS41
1
i01157
