109VX-8R/E and VX-8DR/E Technical Supplement
PCB with Components CB4393001
Printed Circuit Board FR015870B 1-
C 4001 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A A1
C 4002 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- A A1
C 4003 CHIP CAP. 0.5pF 50V CK GRM1554C1HR50BZ01D K22178285 1- A A1
C 4004 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- A A1
C 4005 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- A A1
C 4006 CHIP CAP. 2pF 50V CK GRM1554C1H2R0BZ01D K22178289 1- A A1
C 4007 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- A A1
C 4008 CHIP CAP. 4pF 50V CH GRM1552C1H4R0BZ01D K22178291 1- A A1
C 4009 CHIP CAP. 22pF 50V CH GRM1552C1H220GZ01D K22179707 1- A B1
C 4010 CHIP CAP. 4pF 50V CH UMK105CH040CV-F K22178252 1- A B1
C 4011 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A B1
C 4012 CHIP CAP. 12pF 50V CH GRM1552C1H120JZ01D K22178214 1- A A1
C 4013 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A A2
C 4014 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A A1
C 4015 CHIP CAP. 1pF 50V CK GRM1554C1H1R0BZ01D K22178287 1- A A1
C 4017 CHIP CAP. 1pF 50V CK GRM1554C1H1R0BZ01D K22178287 1- A A2
C 4018 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- A A2
C 4019 CHIP CAP. 27pF 50V CH GRM1552C1H270JZ01D K22178222 1- A A1
C 4020 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- A A2
C 4021 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A B1
C 4022 CHIP CAP. 51pF 50V CH GRM1552C1H510GZ01D K22179710 1- A A2
C 4023 CHIP CAP. 47pF 50V CH GRM1552C1H470GZ01D K22179709 1- A A2
C 4024 CHIP CAP. 4pF 50V CH UMK105CH040CV-F K22178252 1- A B2
C 4025 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A A1
C 4026 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- A A2
C 4027 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A B2
C 4028 CHIP CAP. 33pF 50V CH UMK105CH330JV-F K22178270 1- A B2
C 4029 CHIP CAP. 2pF 50V CK GRM1554C1H2R0BZ01D K22178289 1- A B2
C 4030 CHIP CAP. 1pF 50V CK GRM1554C1H1R0BZ01D K22178287 1- A B2
C 4031 CHIP CAP. 68pF 50V CH UMK105CH680JV-F K22178278 1- A B2
C 4032 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A B1
C 4033 CHIP CAP. 5pF 50V CH UMK105CH050CV-F K22178253 1- A B1
C 4034 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- A B2
C 4035 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- A C2
C 4036 CHIP CAP. 47pF 50V CH UMK105CH470JV-F K22178274 1- A B2
C 4037 CHIP CAP. 10pF 50V CH UMK105CH100DV-F K22178258 1- A B1
C 4038 CHIP CAP. 15pF 50V CH UMK105CH150JV-F K22178262 1- A B1
C 4039 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A B1
C 4040 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A B1
C 4041 CHIP CAP. 10pF 50V CH UMK105CH100DV-F K22178258 1- A B1
C 4042 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A C1
C 4043 CHIP CAP. 10pF 50V CH UMK105CH100DV-F K22178258 1- A B1
C 4044 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A C1
C 4045 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A B2
C 4047 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- A B2
C 4048 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- A B2
C 4050 CHIP CAP. 470pF 25V B TMK063BJ471KP-F K22149901 1-4
C 4051 CHIP CAP. 33pF 50V CH GRM0332C1H330JD01D K22179901 1-4
D 4001 DIODE HVC355B TRF-E G2070588 1- A A1
D 4002 DIODE HSC277TRF-E G2070584 1- A A1
D 4003 DIODE HSC277TRF-E G2070584 1- A A1
D 4004 DIODE 1SV325(TPH3.F) G2070848 1- A A1
D 4005 DIODE HSC277TRF-E G2070584 1- A A2
D 4006 DIODE HSC277TRF-E G2070584 1- A A2
D 4007 DIODE 1SV325(TPH3.F) G2070848 1- A B2
D 4008 DIODE 1SV325(TPH3.F) G2070848 1- A B2
D 4009 DIODE HSC277TRF-E G2070584 1- A B2
D 4010 DIODE 1SS400 TE61 G2070634 1- A B1
Parts List
DESCRIPTION
VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.
REF.
LOT.
SIDE
LAY ADR.
MAIN VCO Unit
