Yaesu VX-8R/E - Page 110

110 VX-8R/E and VX-8DR/E Technical Supplement
MAIN VCO Unit
D 4011 DIODE 1SS400 TE61 G2070634 1- A B1
D 4012 DIODE 1SS400 TE61 G2070634 1- A B1
D 4013 DIODE 1SV325(TPH3.F) G2070848 1- A A2
D 4014 DIODE HSC277TRF-E G2070584 1- A B2
D 4015 DIODE 1SV325(TPH3.F) G2070848 1- A B1
J 4001 CONNECTOR AXK5F10335YP P1091136 1- B b2
J 4002 CONNECTOR AXK5F10335YP P1091136 1- B a2
L 4001 M.RFC 1uH LK1608 1R0K-T L1690687 1- A A1
L 4002 M.RFC 0.0082uH 2% C1608CB-8N2G-RF L1691226 1- A A1
L 4003 M.RFC 0.0082uH 2% C1608CB-8N2G-RF L1691226 1- A A1
L 4004 M.RFC 1uH LK1608 1R0K-T L1690687 1- A B1
L 4005 M.RFC 2.2uH LK1608 2R2K-T L1690634 1- A A1
L 4006 CHIP COIL 0.022uH 2% LQW18AN22NG00D L1690884 1- A A2
L 4007 M.RFC 0.015uH 2% C1608CB-15NG-RF L1691034 1- A A2
L 4008 M.RFC 1uH LK1608 1R0K-T L1690687 1- A B2
L 4009 M.RFC 4.7uH LK1608 4R7K-T L1690688 1- A A2
L 4010 M.RFC 0.1uH 2% C1608CB-R10G-RF L1691045 1- A B2
L 4011 M.RFC 1uH LK1608 1R0K-T L1690687 1- A B1
L 4012 M.RFC 0.33uH LK1608 R33K-T L1690412 1- A B1
L 4013 M.RFC 0.01uH HK1608 10NJ-T L1690516 1- A B1
L 4014 M.RFC 0.1uH LK1608 R10K-T L1690407 1- A C1
L 4015 M.RFC 0.22uH 2% C1608CB-R22G-RF L1691103 1- A B2
Q 4001 TRANSISTOR DTC143ZE TL G3070102 1- A A1
Q 4002 TRANSISTOR MT3S36FS(TE85L.F) G3070377 1- A B1
Q 4003 TRANSISTOR DTC143ZE TL G3070102 1- A A2
Q 4004 TRANSISTOR MT3S36FS(TE85L.F) G3070377 1- A B1
Q 4005 TRANSISTOR MT3S36FS(TE85L.F) G3070377 1- A B1
Q 4006 TRANSISTOR MT3S36FS(TE85L.F) G3070377 1- A B1
Q 4007 TRANSISTOR DTC143ZE TL G3070102 1- A B2
R 4001 CHIP RES. 10k 1/16 W 5 % RMC1/16S 103JTH J24189037 1- A A1
R 4002 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A A1
R 4003 CHIP RES. 47 0 1 /1 6W 5 % RMC1/16S 471JTH J24189021 1- A A1
R 4004 CHIP RES. 1k 1/16W 5 % RMC1/16S 102JTH J24189025 1- A A1
R 4004 CHIP RES. 1k 1/16W 0.5% RR0510P-102-D J24189119 6- A A1
R 4005 CHIP RES. 47 1 /1 6W 5 % RMC1/16S 470JTH J24189009 1- A B1
R 4005 CHIP RES. 47 1 /1 6W 0.5% RR0510R-470-D J24189087 6- A B1
R 4006 CHIP RES. 10k 1/16 W 5 % RMC1/16S 103JTH J24189037 1- A A1
R 4006 CHIP RES. 10k 1/16 W 0.5% RR0510P-103-D J24189143 6- A A1
R 4007 CHIP RES. 47 1 /1 6W 5 % RMC1/16S 470JTH J24189009 1- A B1
R 4007 CHIP RES. 47 1 /1 6W 0.5% RR0510R-470-D J24189087 6- A B1
R 4008 CHIP RES. 10k 1/16 W 5 % RMC1/16S 103JTH J24189037 1- A A2
R 4009 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A A2
R 4010 CHIP RES. 47 0 1 /1 6W 5 % RMC1/16S 471JTH J24189021 1- A A2
R 4011 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- A A1
R 4011 CHIP RES. 2.2k 1/16W 0.5% RR0510P-222-D J24189127 6- A A1
R 4012 CHIP RES. 10 0 1 /1 6W 5 % RMC1/16S 101JTH J24189013 1- A B1
R 4012 CHIP RES. 10 0 1 /1 6W 0.5% RR0510P-101-D J24189095 6- A B1
R 4013 CHIP RES. 10k 1/16 W 5 % RMC1/16S 103JTH J24189037 1- A A2
R 4013 CHIP RES. 10k 1/16 W 0.5% RR0510P-103-D J24189143 6- A A2
R 4014 CHIP RES. 12 0 1 /1 6W 5 % RMC1/16S 121JTH J24189014 1- A B2
R 4014 CHIP RES. 12 0 1 /1 6W 0.5% RR0510P-121-D J24189097 6- A B2
R 4015 CHIP RES. 10k 1/16 W 5 % RMC1/16S 103JTH J24189037 1- A B2
R 4016 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A B2
R 4017 CHIP RES. 3.3k 1/16W 5% RMC1/16S 332JTH J24189031 1- A B2
R 4017 CHIP RES. 3.3k 1/16W 0.5% RR0510P-332-D J24189131 6- A B2
R 4018 CHIP RES. 6.8k 1/16W 5% RMC1/16S 682JTH J24189035 1- A B2
R 4018 CHIP RES. 6.8k 1/16W 0.5% RR0510P-682-D J24189139 6- A B2
R 4019 CHIP RES. 22 0 1 /1 6W 5 % RMC1/16S 221JTH J24189017 1- A B1
R 4019 CHIP RES. 22 0 1 /1 6W 0.5% RR0510P-221-D J24189103 6- A B1
R 4020 CHIP RES. 10 0 1 /1 6W 5 % RMC1/16S 101JTH J24189013 1- A B2
DESCRIPTION
VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.
REF.
LOT.
SIDE LAY ADR.
