75
WIRES-X Software
Main Menu
Settings for the transceiver
Configure the settings such as the usage of the node transceiver and operating frequency.
1 From the “File” menu, select “Transceiver”
The “Transceiver” window will appear.
2 If needed, change the settings or enter values
3 Click [Apply]
The settings will be saved.
Tips • Clicking [OK] saves the settings and closes the “Transceiver” window.
• Clicking [Cancel] closes the “Transceiver” window without saving the settings.
4 Click [OK]
The “Transceiver” window will close.
Operation mode
Select one of the following 4 WIRES-X modes in accordance with your transceiver configuration.
Tip The default setting is Analog.
• Digital .......................................Operates only the voice channel with a transceiver
• Digital DW ................................ Operates the voice channel and preset search channel by dual-watching with a transceiver
Tip Dual Watch Timing setting: The interval time to switch monitoring between the voice channel and preset
search channel can be set from 1 second to 15 seconds in 1 second increment. Normally, set it to 1
second.
Caution When operating in GM mode, this mode cannot be selected.
• Digital Double ...........................Uses one transceiver for the voice channel and the other for the preset search channel
Caution When operating in GM mode, this mode cannot be selected.
• Analog ......................................Operates only the voice channel with an analog transceiver
Caution When operating in GM mode, this mode cannot be selected.
To Next Page
