Yale Conexis L1 - Aligning Handle

11
(09)
INSIDE
OUTSIDE
(09)
INSIDE
OUTSIDE
Please ensure that alignment
tool is at against the door
as screws are tightened. This
ensures the motor is aligned
correctly.
Aligning Handle
•
(09)
INSIDE
OUTSIDE
1
2 3
4
5
6
Ensure exterior handle and xing
plate are parallel before nally
tightening screws.
