3-34
GB
EMU00286
PROCEDURE FOR TILTING UP
Manual tilt model 30
1) Remove the fuel-line connection from
the motor. (If the fuel connector is
provided on the motor.)
2) Place the tilt-lock lever in Release.
3) Hold the rear of the top cowling with
one hand, tilt the engine up, and turn
the tilt-support lever to the locked
position and support the engine.
403024
30
30
EMU00296
PROCEDURE FOR TILTING UP
Power trim/tilt model
1) Remove the fuel-line connection from
the motor.
2) Push the power trim/tilt switch “UP”
until the outboard has tilted up com-
pletely.
3) Push the tilt support knob into the
clamp bracket to support the engine.
w
After tilting the engine, be sure to sup-
port it with the tilt support knob. Other-
wise, the engine could fall back down
suddenly if oil in the power trim/tilt unit
should lose pressure.
403054
