Yamaha 20D - Main Components Overview

2-1
GB
EMU01206
MAIN COMPONENTS
1 Recoil starter handle
2 Choke knob
3 Warning lamp
4 2P connector
5 Gear shift lever
6 Throttle-control grip/
tiller-handle
7 Engine stop button/
Engine stop lanyard
switch
8 Transom-clamp handle
9 Tilt lock lever
0 Trim angle adjusting-rod
q Antisplash plate
w Cooling water inlet
e Propeller
r Trim tab (Anode)
t Anti-cavitation plate
y Battery lead
u Rope attachment
i Shallow water lever
o Wiring harness
p Remote control cable
attachment
a Remote control box
(703 type)
s Fuel tank
* May not be exactly as
shown; also may not be
included as standard
equipment on all models.
20/25N
101203
t
q
w
e
r
y
u
i
o
!1
!8
!6
!7
!9
!4
!3
@0
!0
!2
!5
@2
701013
@1
902051*
*
*
**
*
*
*
