Yamaha 20D - Remote Control

2-8
GB
w
Do not overtighten the friction adjusting
screw/bolt. If there is too much resis-
tance, it may be difficult to move the
throttle grip, which could result in an
accident.
q
w
e
t
701 type
704016*
701011*
w
q
e
t
y
u
r
703 type
ON
OFF START
YAMAHA
703012
r
t
EMU00092
REMOTE CONTROL
Both the shifter and the throttle are actu-
ated by the remote control lever. In addi-
tion, this remote control also has the elec-
trical switches.
1 Remote control lever
2 Neutral interlock trigger
3 Neutral throttle lever
4 Main switch / Choke switch
5 Engine stop lanyard switch
6 Power trim/tilt switch
7 Throttle friction adjusting screw
6L3-9-76A0-2 2/27/03 10:20 AM Page 18
