3-6
GB
EMF31010
FILLING FUEL AND
ENGINE OIL
FILLING FUEL
1) Remove the fuel tank cap.
2) Fill the fuel tank carefully.
3) Close the cap securely after refueling.
Wipe up any spilled fuel.
EMU01800
FILLING OIL
For oil injection system models
This engine uses the oil injection system,
which provides superior lubrication by
ensuring the proper oil ratio for all operat-
ing conditions. No fuel premixing is need-
ed (except during break-in). Simply pour
gasoline into the fuel tank and oil into the
oil tank. Convenient indicator segments
indicate the status of the oil supply. For
details on reading the indicator segments,
see “Oil level indicator” in this chapter.
To fill the engine oil tank, proceed as fol-
lows:
w
Do not add gasoline into the oil tank. Fire
or explosion could result.
Fuel tank capacity:
Refer to SPECIFICATIONS, page 4-1.
Engine oil tank capacity:
See Chapter 4, “Specifications.”
