– 10 –
SPEC
CABLE ROUTING
Ï 80 mm (3.15 in)
Ð Fasten the starter motor lead and A.C. magneto
lead to the frame with a plastic band. The end of
the plastic band should be toward the rear of the
vehicle, facing inward.
Ñ Fasten the starter motor lead and A.C. magneto
lead with a plastic locking tie.
Ò Fasten the A.C. magneto lead with the holders.
Ó Route the A.C. magneto lead on top of the
crankcase.
Ô Face the end of the plastic band inward. (for
Europe)
A B-B
7
7
Ô
1
È
2
3
4
Ë
5
6
Ì
Í
Î
7
8
É
9
ÑÐ
0A
ÒÓÒ
Ê
B
A
B
Ï
