4-1
Outboard Rigging Guide - 2001
CONTROL BOXES
701 Control Box
701-48101-51-00 Pull to open throttle. Non electric start models, starboard mount only.
(PULL/MANUAL)
701-48130-02-00 Push to open throttle. Non electric start models, starboard mount only.
(PUSH/MANUAL)
703 Standard Control Box
703-48230-12-00 Pull to open throttle. 7-pin harness with push to choke main switch.
(PULL/7-PIN/CHOKE)
703-48207-15-00 Push to open throttle. 10-pin harness, push to choke main switch and
power trim & tilt switch. (PUSH/10-PIN/CHOKE/PT&T)
704 Single Binnacle Control Box
704-48205-13-00 Push to open throttle with power trim and tilt switch. Can be converted
to pull to open throttle. (SNG BINN/PUSH/PT&T)
704 Dual Binnacle Control Box
704-48207-31-00 Push to open throttle with power trim and tilt switch. Can be converted
to pull to open throttle. (DUAL BINN/PUSH/PT&T)
705 Flush Mount Control Box
6X0-48206-11-00 Push to open throttle with power trim and tilt switch.
Note: 90° quick throw handle movement. (FLUSH/PUSH/PT&T/90°)
NOTE: 8, F9.9, T9.9, 25, & 30 use a pull to open throttle control with a 7 pin harness.
T8~9.9, 15, and 40hp to 250hp use a push to open throttle control with a 10 pin harness.
The 9.9 and 15 use a 7 pin to 10 pin adapter harness. The trim switch will not operate on
models without power tilt or power trim.
All Prime Start™ Engines - The choke function has no affect on Prime Start.
(Refer to chart on page 4-3)
