2-25
Outboard Rigging Guide - 200128
Jet Drive Eng. Mtg., Maintenance,
‘95 and Later
REF
NO PART NO. DESCRIPTION QTY.
63D-J0001-38-20 Shift Cable Assembly 1
A 63D-JD005-47-00 Cable 4 ft 1
B 6H4-JD005-43-00 Clamp, Cable 1
C 6H4-JD005-61-00 Bolt, Cable Clamp 2
D 63D-JD005-58-02 Screw, Hex Head 1
E 6H4-JD006-19-00 Nut, Fiberlock 2
F 62D-JD005-53-02 Ball Rod End 1
G 63D-JD006-21-01 Nut, Hex 1
H 6H4-J0006-37-00 Lock Washer
Toothed M5 1
