Yamaha 85AED - Page 117

3-29
REMOTE SWITCH TYPES AND APPLICATIONS
EMERGENCY STOP SWITCH W/ PANEL
Ref. No. Part No. Description
1 64D-82570-10 w/ bullet connectors for stop SW
2 64D-82570-30 w/ 2P coupler for stop SW
3 6X6-82570-90 For Digital Network System (6Y9), 2nd station helm, Single/Twin/Triple engine application
4 6X6-82570-V0 For Digital Network System (6Y9), Quad engine application only
63 (2.48)
63 (2.48)
9 (0.35)
W
B
1000 (39.4)
47 (1.85)
47 (1.85)
54 (2.12)5.6 (0.22)
63 (2.48)
63 (2.48)
9 (0.35)
1000 (39.4)
47 (1.85)
47 (1.85)
54 (2.12)5.6 (0.22)
BW
1
2
3
4
mm (in.)
mm (in.)
mm (in.)
mm
(in.)
Clearance:
10 – 30 mm,
0.39 – 1.18 in
53 (2.07)
1000 (39.4)
12
(0.47)
55 (2.17)
50 (1.97)
38.1 (1.5)
33.4 (1.31)
5.6 (0.22)
38.4
(1.51)
WWW
BBB
WWW
BB
B
55 (2.17)
38.1 (1.5)
50 (1.97)
33.4 (1.31)
5.6 (0.22)
(1000 (39.37))
38.4
(1.51)
