Yamaha AG03MK2 - Page 72

Analog Output Characteristics (AG06MK2)
0 dBu = 0.775 Vrms
Output Terminals
Actual Source
Impedance
At Nominal Level
Output level
Connectors
Nominal Max. before clip
STEREO OUT [L,
R]
150 Ω 10 kΩ lines
0 dBu
(0.775 V)
+10 dBu
(2.451 V)
Phone jack *7
(impedance
balanced)
MONITOR OUT [L,
R]
150 Ω 10 kΩ lines
0 dBu
(0.775 V)
+10 dBu
(2.451 V)
Phone jack *7
(impedance
balanced)
PHONES 120 Ω 40 Ω phone 1.5 mW + 1.5 mW 6 mW + 6 mW
Phone jack
3.5 mm phone jack
AUX OUT 150 Ω 1.5 kΩ line
−30 dBu
(24.51 mV)
−20 dBu
(77.50 mV)
3.5 mm phone jack
*8
(CTIA)
*7 Tip = HOT, Ring = COLD, Sleeve = GND
*8 Tip = Signal L, Ring 1 = Signal R, Ring 2 = GND, Sleeve = Output for smartphone
Digital Input / Output Characteristics (AG06MK2)
Terminals Format Data Length Fs Connectors
USB
USB Audio Class 2.0 /
Yamaha Steinberg USB
Driver
24-bit
44.1 kHz, 48 kHz,
88.2 kHz, 96 kHz,
176.4 kHz, 192 kHz
USB Type-C
Analog Input Characteristics (AG03MK2)
0 dBu = 0.775 Vrms
Input Jacks
PAD
26 dB
GAIN Trim /
SW
Position
Actual Load
Impedance
At Nominal
Level
Input level
Connectors
Sensitivity
*1
Nominal
Max.
before clip
MIC / LINE 1
HEADSET
MIC
OFF
10
3 kΩ
1.5 kΩ*4
50 Ω – 600 Ω
mic / line
−72 dBu
(0.195 mV)
−60 dBu
(0.775 mV)
−50 dBu
(2.451 mV)
Combo jack
*2
(balanced)
3.5 mm
phone jack
for
HEADSET
MIC
(plug-in
power /
unbalanced)
0
−26 dBu
(38.84 mV)
−14 dBu
(154.6 mV)
−4 dBu
(489.0 mV)
ON
10
−46 dBu
(3.884 mV)
−34 dBu
(15.46 mV)
−24 dBu
(48.90 mV)
0
0 dBu
(775.0 mV)
+12 dBu
(3.085 V)
+22 dBu
(9.757 V)
GUITAR 2G -
HIGH
1 MΩ -
−32 dBu
(19.5 mV)
−20 dBu
(77.5 mV)
−10 dBu
(245.1 mV)
Phone jack
*3
(unbalanced
)
LOW
−12 dBu
(194.7 mV)
0 dBu
(775.0 mV)
+10 dBu
(2.451 V)
72
Appendix > Input / Output characteristics
