Yamaha AG03MK2 - Page 73

LINE 2 / 3 -
HIGH
10 kΩ 600 Ω lines
−20 dBu
(77.50 mV)
−8 dBu
(308.5 mV)
+2 dBu
(973.7 mV)
Phone jack
*3
(unbalanced
)
LOW
−10 dBu
(245.1 mV)
+2 dBu
(975.7 mV)
+12 dBu
(3.085 V)
AUX INPUT - - 10 kΩ 600 Ω lines
−14 dBu
(154.6 mV)
−8 dBu
(308.5 mV)
+2 dBu
(975.7 mV)
3.5 mm
phone jack
*5 (CTIA)
*1 Sensitivity is the lowest level that will produce an output of +0 dBu (0.775 V) or the nominal output level
when the unit is set to maximum gain. (All level controls are at their maximum position.)
*2 1 & Sleeve = GND, 2 & Tip = HOT, 3 & Ring = COLD
*3 Tip = Signal, Sleeve = GND
*4 For CH 1, HEADSET MIC
*5 Tip = Signal L, Ring 1 = Signal R, Ring 2 = GND, Sleeve = Output for smartphone
Analog Output Characteristics (AG03MK2)
0 dBu = 0.775 Vrms
Output Terminals
Actual Source
Impedance
For Use With
Nominal
Output level
Connector
Nominal Max. before clip
MONITOR OUT [L,
R]
150 Ω 10 kΩ lines
0 dBu
(0.775 V)
+10 dBu
(2.451 V)
Phone jack *6
(impedance
balanced)
RCA pin
(unbalanced)
PHONES 120 Ω 40 Ω phone 1.5 mW + 1.5 mW 6 mW + 6 mW
Phone jack
3.5 mm phone jack
AUX OUT 150 Ω 1.5 kΩ line
−30 dBu
(24.51 mV)
−20 dBu
(77.50 mV)
3.5 mm phone jack
*7
(CTIA)
*6 Tip = HOT, Ring = COLD, Sleeve = GND
*7 Tip = Signal L, Ring 1 = Signal R, Ring 2 = GND, Sleeve = Output for smartphone
Digital Input / Output Characteristics (AG03MK2)
Terminals Format Data Length Fs Connector
USB
USB Audio Class 2.0 /
Yamaha Steinberg USB
Driver
24-bit
44.1 kHz, 48 kHz,
88.2 kHz, 96 kHz,
176.4 kHz, 192 kHz
USB Type-C
