Yamaha CDX-E200 - Printed Circuit Board

ABCDEFGH
1
2
3
4
5
6
CDX-E200
■ PRINTED CIRCUIT BOARD (Foil side)
E-23/J-21E-22/J-20
J, R, G only
J, R only
R only
G only
BR BR WH OR YE RE BE
GR
GR
BR
YE
BR
RE
OR
WH
BE
AC
OUTLET
VOLTAGE
SELECTOR
(R only)
FROM : POWER DORD
FL2 FL1 AC GND AC
TO : MAIN (1)
W401
L402
#7
MAIN ( 4 ) P. C. B. MAIN ( 5 ) P. C. B.
FROM : MAIN (2)
FL1
/BLK
CL
GND
+5
K1
KD1
FL2
CE
DI
VP
K2
K0
KD0
MAIN ( 3 ) P. C. B.
PLAY
PAUSE
STOP
T/ER/Y
STANDBY/
ON
OPEN/
CLOSE
3
1
16
17
32
64
49
48
33
Point e (Pin 58 of IC301)
V : 2V/div, H : 0.2µsec/div
DC, 1 : 1 probe
0V
CIRCUIT CHANGES BY MARKET.
RBGJ
CB402, 403 X X O X
F401 X X O X
J401 X O O O
SW501 O X X X
TE501 O X O O
ST501 O X O O
MAIN (5) O X O O
O : USED
X : NOT USED
110V RE – YE
120V OR – YE
220V WH – YE
240V BE – YE
SW501
