Yamaha CDX-E200 - Rear Panel and Specifications; Rear Panel Layout; Technical Specifications and Dimensions

CDX-E200
CDX-E200
■ REAR PANELS
3
▼ R model
▼ G model
▼ B model
● DIMENSION
Unit : mm (inch)
■ SPECIFICATIONS
Output Level
1kHz, 0dB 2.0 ± 0.5Vrms
Signal to Nosie Ratio (EIAJ) 102dB
Dynamic Range 95dB
Harmonic Distortion+Noise (1kHz) 0.004%
Frequency Response
2Hz — 20kHz ±0.5dB
Power Requirements
B, G models 230V AC 50Hz
R model 110/120/220/240V AC 50/60Hz
Power Consumption 13W
Dimensions (W x H x D) 217 x 108 x 290mm
(8-9/16" x 4-1/4" x 11-7/16")
Weight 3.0kg (6 lbs 9 oz)
Finish
Gold color R, G, B models
Silver color G, B models
*Specifications are subject to change without notice.
B .................... British model
G ............... European model
R .................. General model
217(8-9/16")
100(3-15/16")
8
(5/16")
108(4-1/4")
3
(1/8")
12
(1/2")
275(10-13/16")
290(11-7/16")
240V
*
*
*
