! : Note on the Main PCB
Of the main PCB part Nos., only the gold (GD) type part Nos. are included in the table.
The only different part between the silver (SI) and gold (GD) type parts is the sheet/FL that is attached to the
fluorescent character display tube. When a SI type main PCB becomes necessary, order a GD type main PCB and a
SI type sheet/FL (V3688400) and replace the sheet/FL of the GD type main PCB with the SI type sheet/FL.
Schm
Ref. PARTNO. Description Market
NewParts
*
Schm
Ref. PARTNO. Description Market
NewParts
*
! * V6987600 P.C.B. MAIN R
! * V7019300 P.C.B. MAIN B
! * V7020300 P.C.B. MAIN G
CB1 V2731000 CN.FMN 16P
CB2 VB390200 CN.BS.PIN 6P
CB3 VB390100 CN.BS.PIN 5P
CB4 VQ963800 CN.BS.PIN 17P
CB5 VQ964100 CN.BS.PIN 20P
CB6 VT707200 L.EMIT TOTX178
CB7 VB390100 CN.BS.PIN 5P
CB8 VQ962400 CN.BS.PIN 3P
CB101 VQ962000 CN.BS.PIN 17P
CB102 VN394900 CN.BS.PIN 14P
CB103 VQ962300 CN.BS.PIN 20P
CB104 VQ960600 CN 3P
CB301 VF982200 CN.BS.PIN 14P
CB401 VG879900 CN.BS.PIN 2P
CB402 VP206500 HOLDER.FUS EYF‑52BCT G
CB403 VP206500 HOLDER.FUS EYF‑52BCT G
C1 UR818100 C.EL 100uF6.3V
C2 VJ599100 C.CE.TUBLR 0.1uF50V
C3 UR818100 C.EL 100uF6.3V
C4 UR818100 C.EL 100uF6.3V
C5 UR837470 C.EL 47uF16V
C6 VF467000 C.CE.TUBLR 1000pF50V
C7 UR866100 C.EL 1uF50V
C8 UR838100 C.EL 100uF16V
C9 UR818100 C.EL 100uF6.3V
C10 UR818100 C.EL 100uF6.3V
C11 UA655100 C.MYLAR 0.1uF50V
C12 UN865220 C.EL 0.22uF50V
C15 Vi717000 C.MYLAR 0.018uF50V
C16 Vi716100 C.MYLAR 3300pF50V
C19 Vi716100 C.MYLAR 3300pF50V
C20 Vi717000 C.MYLAR 0.018uF50V
C21 VG287300 C.EL 22uF50V
C22 VG287300 C.EL 22uF50V
C23 Vi715900 C.MYLAR 2200pF50V
C24 Vi715900 C.MYLAR 2200pF50V
C25 UA652220 C.MYLAR 220pF50V
C26 UA652220 C.MYLAR 220pF50V
C27 VF466800 C.CE.TUBLR 100pF50V
C28 VF467300 C.CE.TUBLR 0.01uF16V
C29 VJ599100 C.CE.TUBLR 0.1uF50V
C30 UR848220 C.EL 220uF25V
C31 UR818100 C.EL 100uF6.3V
C32 VJ599100 C.CE.TUBLR 0.1uF50V
C33 UR865680 C.EL 0.68uF50V
C34 UR818100 C.EL 100uF6.3V
C35 UR837100 C.EL 10uF16V
C36 VG287900 C.EL 470uF16V
Z C37 FG644100 C.CE 0.01uF50V
C38 Vi578400 C.EL 6800uF16V
Z C39 FG644100 C.CE 0.01uF50V
C40 UR837470 C.EL 47uF16V
C41 UR828100 C.EL 100uF10V
C42 UR867470 C.EL 47uF50V
C43 UR866470 C.EL 4.7uF50V
C44 UR866470 C.EL 4.7uF50V
C45 UR866470 C.EL 4.7uF50V
C46 UR866470 C.EL 4.7uF50V
C47 UR868100 C.EL 100uF50V
C48 FG644100 C.CE 0.01uF50V
C101 VJ599100 C.CE.TUBLR 0.1uF50V
C102 VJ599100 C.CE.TUBLR 0.1uF50V
C103 VJ599100 C.CE.TUBLR 0.1uF50V
C104 V4749000 C.EL 150uF6.3V
C105 VG277500 C.CE.TUBLR 56pF50V
C106 UA653100 C.MYLAR 1000pF50V
C107 UA653150 C.MYLAR 1500pF50V
C108 UA654470 C.MYLAR 0.047uF50V
C109 UN865470 C.EL 0.47uF50V
C110 UA655100 C.MYLAR 0.1uF50V
C111 V4749000 C.EL 150uF6.3V
C112 UR818100 C.EL 100uF6.3V
C113 VJ599100 C.CE.TUBLR 0.1uF50V
C114 VJ599000 C.CE.TUBLR 0.047uF16V
C115 UN865100 C.EL 0.10uF50V
C116 UA654390 C.MYLAR 0.039uF50V
C117 UA653560 C.MYLAR 5600pF50V
C118 UA954470 C.MYLAR 0.047uF50V
C120 VF466700 C.CE.TUBLR 47pF50V
C122 VJ599100 C.CE.TUBLR 0.1uF50V
C123 VG278700 C.CE.TUBLR 390pF50V
C124 UR837470 C.EL 47uF16V
C125 UA654680 C.MYLAR 0.068uF50V
C126 VJ599100 C.CE.TUBLR 0.1uF50V
C127 UA655100 C.MYLAR 0.1uF50V
C128 VJ599100 C.CE.TUBLR 0.1uF50V
C129 VJ599100 C.CE.TUBLR 0.1uF50V
C130 VA761400 C.CE 47pF50V
C131 VA761400 C.CE 47pF50V
C132 VG290600 C.EL 2.2uF50V
C133 VG290600 C.EL 2.2uF50V
C134 VG290600 C.EL 2.2uF50V
C135 VG290600 C.EL 2.2uF50V
C136 VG286500 C.EL 470uF10V
C137 VJ599100 C.CE.TUBLR 0.1uF50V
C138 UR818100 C.EL 100uF6.3V
C139 VJ599100 C.CE.TUBLR 0.1uF50V
C140 VJ599100 C.CE.TUBLR 0.1uF50V
C141 VJ599100 C.CE.TUBLR 0.1uF50V
C142 VJ599100 C.CE.TUBLR 0.1uF50V
C143 UR818100 C.EL 100uF6.3V
C144 VF467300 C.CE.TUBLR 0.01uF16V
C145 UA652120 C.MYLAR 120pF50V
