Tracking gain rough ADJ
~ * Data fetch cycle ~
After searching the beginning, MUTE is cancelled.
~ PLAY ~
MUTE ON
TRACK search
MUTE ON
Spindle motor stop
: MUTE OFF = “H” → “L” (Q7 Collector)
“0:00” appears in the time indicator.
Tracking balance ADJ (only tray OPEN/CLOSE)
Focus balance ADJ
Focus gain ADJ
Tracking gain ADJ
* TOC READ
TRACK NO. “1” is searched.
Set to SEARCH by means of Y, T key.
After searching the beginning, MUTE is cancelled.
~ PLAY ~
Press the STOP key.
Laser OFF
Forced feed return
~ STOP ~
: MUTE ON = “L” → “H” (Q7 Collector)
: MUTE ON = “L” → “H” (Q7 Collector)
: FLSW (IC103, 21 pin) = “L”
: MUTE OFF = “H” → “L” (Q7 Collector)
“0:00” appears in the time indicator.
: LSOFF = “L” → “H” (IC101, 2 pin)
